Bosch Smart System with Performance CX e-drive and Kiox 300 display plus 750 Wh battery

180 mm travel FOX 38 Factory suspension fork and 170 mm F.O.L.D. kinematics with FOX DHX coil rear shock

Fully integrated C.I.S. cable routing with reliable precise Shimano XT 1x12 shifting, strong XT 4-piston brakes and RaceFace AR30 Offset

Bosch CX e-drive & 750 Wh battery

180 mm FOX 38 Factory fork & 170 mm FOX DHX coil shock

Shimano XT 1x12 & RaceFace AR30 Offset

MAXXIS Minion DHF, 2.6 EXO / MAXXIS MINION DHRII, 2,6 EXO

• Charger
  • 750 Wh
• Brake
  • 203 mm
• Frame size
  • S,M,L,XL
  • 39,42,44,46
• Drive train
  • chain
• Wheelset
  • RaceFace AR30 Offset
• Max total weight
  • 150
• Frame
  • 7005 hydroformed Aluminium, 3D forging, 170 mm F.O.L.D. Gen2, 148x12 mm thru axle, internal cable routing, USB-C port, post mount 203 mm
• Fork
  • FOX 38 Factory Float 29, Grip 2, E-Bike , 110x15 mm, 44 mm rake
• Handlebar
  • RaceFace Atlas 35, Aluminium, 820 mm, rise: 35 mm, backsweep: 8°
• Saddle
  • Fizik Terra Aidon
• Seat post
  • Post Moderne dropper post PM-214, 34.9 mm
• Stem
  • FOCUS C.I.S. 2.0 MTB , 35 mm, aluminium
• Brakes
  • Shimano XT M8120, 4 piston,Shimano XT M8120, 4 piston
• Crank set
  • RaceFace Aeffect R e-Optimized Bosch G4
• Switch lever
  • Shimano Deore XT M8100, 12-speed
• Sprocket
  • Shimano SLX M7100, 12-speed
• Transmission
  • front: 36, rear: 10-51
• Headset
  • ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8" angle headset
• Tyres
  • Schwalbe Magic Mary, 2.6 Super Trail Soft, 65-622
• Tyres, rear
  • Schwalbe Magic Mary, 2.6 Super Gravity Soft, 65-622
• specs.ProductRearBrakeDescription
  • Shimano XT M8120, 4 piston
• Disc brake rotor, front
  • 203 mm
• Disc brake rotor, rear
  • 203 mm
• Battery
  • Bosch PowerTube Li-Ion (750Wh)
  • 750 Wh
• Display
  • Bosch LED Remote Kiox 300
• Motor
  • Bosch Performance CX Smart, 85 Nm, 250 W
• Colour
  • Lightgrey glossy, Moonstonegrey glossy
• Travel
  • 180 mm
• Grip
  • RaceFace Getta Grip
• Rear derailleur
  • Shimano Deore XT M8100, 12-speed
• Tire
  • Schwalbe Magic Mary, 2.6 Super Trail Soft, 65-622
  • Schwalbe Magic Mary, 2.6 Super Gravity Soft, 65-622
• Shift/brake lever
  • Shimano Deore XT M8100, 12-speed
• Chain
  • Shimano SLX CN-M7100, 12-speed
• Shock
  • FOX DHX Performance Coil, 230/65 mm, hardware: 20,0 x 8.0 mm
